• Unicla 10-cylinder swashplate
  • Suitable for larger commercial and bus applications with a system capacity requirement of 12-16 kW
  • Displacement: 380 cc/rev
  • Maximum continuous: 4500 rpm
  • Smooth and quiet operation with excellent performance through all rev ranges
  • Clockwise and counterclockwise rotation with no change in volumetric efficiency
  • Heavy duty impressed steel gasket and HNBR Japanese high-temperature O-ring (two-point seal)
  • Forged steel cylinder housing
  • Drop-forged 5050 aluminium pistons with synthetic PTFE heat-treated rings
  • Lip seal with high tolerance to heat and operational fatigue
  • Genuine NSK bearings throughout
89 Un380
R134a | R513a refrigerant
Compressor Oil Mounting
UN380 PAG56 or POE68 (600 ml) Denso 10P30B compatible
R1234yf refrigerant
Compressor Oil Mounting
UNY380 PAG46 HD (600ml) Denso 10P30B compatible

The Multi Direct Mounting system on UN models provides a total of eight mounting points (four on both the left and right sides), enabling direct compatibility with Denso 10P30B compressors. Mounting points on each side of the compressor are 94 mm and 81 mm apart.

Low- and high-side service valves are fitted to the rear cap.

An oil return port is not fitted.

Both ports are fitted with a shut-off manifold assembly with back seating capability via stem valves.

Type 158 168 178 210 12V 24V HDC

Pulley measurements are in millimetres
